9
Remote Switch LEDs Do Not Mimic the Front Panel LEDs
e remote switch LEDs should display the same status information that is on the WF-
5118/5120 Inverter front panel. Check the remote switch cable that runs between the rear panel
of the inverter to the back of the remote switch. Make sure the female DB9 connector is fully
seated into the male DB9 connector on the rear panel. Tighten the two thumbscrews on either
side of the cable connector. On the opposite end of the cable, make sure the 10-pin single row
connector is fully seated into the back of the remote switch.
If the remote switch does not display the proper information, replace the remote switch and
check for proper operation. If the remote switch will not work, replace the connecting cable.
Unit Has Pass-rough but Nothing Works (Power Button in ON Position)
Make sure the WF-5118/5120 Inverter’s Power Pushbutton is in the OFF position. Disconnect
the Negative (White) wire from the DC input lugs at the rear panel. Let the unit stand idle for
approximately 5 minutes so the internal circuitry can normalize. Reconnect and securely tighten
the Negative (White) wire. Push the Power Pushbutton to the ON position. e unit should
work normally.
Contact the Arterra Distribution Power PROs at 1 (877) 294-8997.
