3
!WARNING!
Risk of Electrical Shock. Disconnect or isolate all power supplies before making electrical
connections. More than one disconnection or isolation may be required to completely
de-energize equipment. Contact with components carrying hazardous voltage can cause
electric shock and may result in severe personal injury or death.
!IMPORTANT!
All wiring must conform to local, national, and regional regulations. Use copper conductors only
for all wire connections. Do not exceed the electrical ratings for the WF-5118/5120 Inverters or
the equipment connected to it.
!CAUTION!
is product should be installed by an experienced technician. CAUTION and care must be
taken when servicing this equipment. To prevent severe shock or electrocution, consult your
servicing dealer.
!WARNING!
is unit employs components that can produce arcs or sparks. To prevent re or explosion, do
not install in compartments containing batteries or ammable materials (LP gas). is product
is NOT ignition protected.
!CAUTION!
To prevent re, do not cover or obstruct front cover ventilation openings. For continued
protection against risk of re or electric shock, replace faulty DC fuses and AC breakers
with ones of the same type and ratings as are installed.
!CAUTION!
When using a battery with the WF-5118/5120 Inverters, follow battery maintenance procedures.
Check the uid level in any battery connected to RV charging system on a monthly basis.
GENERAL INFORMATION
e WF-5118/5120 Inverters are standalone power inverters with AC Pass-rough suitable for
use in RV, Marine, and other applications where a True Sine Wave 115 VAC voltage is required.
e WF-5118 inverter will produce 1800 Watts of AC power. e WF-5120 inverter will produce
2000 Watts of AC power.
When 115 VAC utility power is applied to the WF-5118/5120 Inverters through the Shore cord,
115 VAC will pass straight through to the connected load. Should utility power be cut o, the
WF-5118/5120 Inverters automatically switch to invert mode, providing clean 115 VAC to the
connected load. When utility power is reapplied, the WF-5118/5120 switches back to the Pass-
rough mode.
e WF-5118/5120 Inverters require 12 VDC (nominal) input from the house battery to operate
in the inverting mode. For Pass-rough mode, a convenient internal wiring box is located on
the rear panel, along with the hardwire output.
Please read all instructions and cautionary statements in this manual before installation and use
of the WF-5118 and WF-5120 Inverters.
