7. INSTRUCTIONS FOR USE
This Whale® Compac 50 is designed to only require minimal maintenance.
WARNING: Before servicing, turn off the power and drain water from system.
Optimal Performance
• For optimal performance, regular inspection of the pump for debris and damage is recommended.
• Rubber components are perishable and susceptible to damage. They should be inspected periodically and replaced as necessary
The following service kits are available, please visit www.whalepumps.com for more information or for details of a local retailer:
AK8035 - Whale Compac 50 - diaphragm, valves and xings AS0356 - Whale Compac 50 - Deckplate Kit
AS0353 - Clamping Ring Kit AS0355 - Spare Handle
Changing the Diaphragm and Valves
Diaphragm:
1. Slacken and remove the clamping ring screws and remove clamping rings (hoses may be left attached).
2. Remove clamping plate screw and clamping plate.
3. Replace diaphragm ensuring the centre portion of the diaphragm projects into valve chamber.
4. Check diaphragm is “seated” in the cover grooves.
Valves:
1. Unscrew the 4 self tapping screws at the base of the inlet/outlet nipples (hoses can be left attached).
2. Remove and replace the valves ensuring that they are correctly seated in the pump body groove.
3. Replace the nipples in their mounting position and secure in place.
3. Position the pump underdeck and check ow direction.
4. Work the rubber gaiter up through the hole until its ange rests on the deck.
5. Place deck plate cover on top of the deck and secure with the 4 screws provided into the pump body.
6. Attach 1” I.D. (25 mm) smooth bore reinforced hose with stainless steel wormdrive hose clips. Tighten the clips to prevent air
leaks.
7. With thru-hull discharge, make sure that the discharge point is above the water line.
8. Check the installation for air leaks, correct priming and discharge.
10. WINTERIZING
12. WARRANTY
11. SERVICE SUPPORT DETAILS
13. PATENTS AND TRADEMARKS
NOTE When winterizing, fully drain system.
Whale® does not cover damage, caused by the system not being not fully drained for winterizing.
Whale® Compac 50 is guaranteed for 5 year from date of purchase. The rubber components are guaranteed for 1 year from date of
purchase. Please refer to the enclosed document for details of our Statement of Limited Warranty.
For installation or service advice please contact Whale® Customer Support:
UK Tel: +44 (0)28 9127 0531 Email: info@whalepumps.com
USA Tel: 1 802 367 1091 Email USA: usasales@whalepumps.com
Whale® is a registered trademarks of Munster Simms Engineering limited (also trading as Whale® Seaward Inc).
Copyright Whale 2015- All rights reserved.
WHALE®, is a registered trademark of Munster Simms Engineering Limited, Bangor Northern Ireland (trading as Whale). Whale’s policy is one of
continuous improvement and we reserve the right to change specications without prior notice. Illustrations are for guidance purposes only.
14. APPROVALS
This product complies with all relevant European directives and standards. Please contact Whale® if further details are required.
The Whale Compac 50 ensures efcient throughput with an easy pumping action. Full even strokes will obtain the best results. Two clips
are provided for storing the handle when the pump is not in use.
Output At 45 Strokes/Min At 70 Strokes/Min
US Gal/min 9 9.2
Litres/min 32 35
8. MAINTENANCE
Please note: Performance data is based on factory tests and is typical
of what may reasonably be achieved. Actual performance may vary
depending on installation and operating conditions.
9. TROUBLESHOOTING
Pump fails to prime or chokes:
• Check inlet hose connection is airtight and does not collapse during the suction stroke.
• Inspect inlet and outlet valves for blockages. Clear with nger or screwdriver and test.
• Solid objects in the body of the pump should not prevent operation but must be removed to prevent damage.
