Model Name DP-4100 DP-4120
Stereo Power Output
8 ohms 4x1000W
4 ohms 4x1700W
Bridged Mono Output
16 ohms 2x2000W
8 ohms
Input Sensitivity & impedance
Sensitivity selectable 38/35/32/29dB selectable 41/38/35/32dB
Balanced XLR input 20Kohms 20Kohms
Maximum Input Level 22dBu (9.7Vrms) 22dBu (9.7Vrms)
Voltage Gain
38dB 41dB
Crosstalk <-90dB <-90dB
S/N >
109dB >110dB
Distortion (1W) <0.02% <0.02%
Frequency Response
+/-1dB @ 8 ohms 20Hz - 20KHz 20Hz - 20KHz
+/-3dB @ 8 ohms 20Hz - 30KHz 20Hz - 30KHz
Damping Factor >5000 >5000
Topology Class D Class D
Connectors
Signal Input
Female XLR Jacks Female XLR Jacks
Power Output SPEAKON Jacks SPEAKON Jacks
Controls
Front panel
Rear panel
Protections
Thermal protect, Over-current protect, Output DC protect, Output short protect
Indictors
Cooling Variable Speed Fan
AC Power
Dimensions 44x485x370mm 44x485x465mm
Carton Box
Weight (Net)
Weight (Gross)
9kg 14kg
SPECIFICATION
2x3400W
4x1200W
4x2040W
2x2400W
2x4080W
8kg 13kg
Power, Mode, Temperature, Signal, Peak, Fault
90-260 VAC~50/60Hz
14
AC Switch, 4xCH gain knobs
Gain Switch; Mode Switch; Limiter Switch
