Model Name DP-2200
Stereo Power Output
8 ohms 2x2000W
4 ohms 2x3400W
Bridged Output
16 ohms 1x4000W
8 ohms
Input Sensitivity & impedance
Sensitivity selectable 41/38/35/32dB
Balanced XLR input 20Kohms
Maximum Input Level 22dBu (9.7Vrms)
Slew Rate >50V / us
Crosstalk <-90dB
S/N >
112dB
Distortion (1W) <0.02%
Frequency Response
+/-1dB @ 8 ohms 20Hz - 20KHz
+/-3dB @ 8 ohms 20Hz - 30KHz
Damping Factor >5000
Topology Class D
Connectors
Signal Input and Output Female and Male XLR Jacks
Power Output SPEAKON Jacks
Controls
Front panel
Rear panel
Protections
Thermal protect, Over-current protect, Output DC protect, Output short protect
Indictors Power, Mode, Temperature, Signal, Peak, Fault
Cooling Variable Speed Fan
AC Power
Dimensions
44x485x370mm
Carton Box
Weight (Net)
Weight (Gross)
9kg
SPECIFICATION
1x6800W
90-260 VAC~50/60Hz
8kg
AC Switch, Gain Knobs
15
Gain Switch; Mode Switch; Limiter Switch
