09
There’s a power switch beside the battery charging port. Remember to turn the battery power switch
to “ I ” if you plan to use the throttle and/or battery power. For regular pedaling without power and/or
after you are done riding, turn the battery power switch to “ O ” to power the battery OFF.
First, open the clamp under the seat post. Pull the seat up or push it down to adjust height.
Check to make sure the seat post is fully inserted into the frame and the head of the seat is
parallel with the frame. Lastly, close the clamp to secure the seat in place (fig. 6).
2.5 Installing the battery
The battery is seperated packaged in the box. After assembling the parts above,
insert the battery into the battery base on the middle frame. Turn the key to the locked position.
To unlock the battery, insert the key, and turn it to the unlock position to pull the battery out.
Latch
fig. 6
OFF/ON
