PART IDENTIFICATION
Air filter
(behind the front intake grille)
Front intake grille
Control panel cover
Power cord
Front grille
Air inlet louver
Cabinet
Vertical airflow direction vane
(Airflow direction adjustment up and down).
The vertical airflow direction vane is controlled by
positioning the vane to discharge the air upwards,
downwards or straight out.
Air direction adjustment
Panel outlook picture, just for reference, please take the real unit as standard.
