Unpack the Air Conditioner
Remove packaging materials
• Remove and dispose of/recycle packaging materials. Remove tape and glue residue from surfaces before
turning on the air conditioner. Rub a small amount of liquid dish soap over the adhesive with your
fingers. Wipe with warm water and dry.
• Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or
glue. These products can damage the surface of your air conditioner.
Install Portable Air Conditioner
Install Exhaust Hose and Adapter
1. Roll air conditioner to selected location. See
"Location Requirements."
2. Insert hose adapter into slot on the back of air
conditioner.
3. Slide down to lock hose into place.
4. open the window, place the window exhaust
nozzle to the window down to lock hose into
place.
5. Extend the Exhaust hose and close the window
as much as possible to trap the exhaust nozzle as
below shown.
INSTALLATION INSTRUCTIONS
A. Evaporator air intake
B. Hose adapter
C. Flexible exhaust hose
D. Window exhaust adapter
15
INDOOR
INDOOR
Open Type window
INDOOR
Vertical Slide Window
INDOOR
Horizontal Slide Window
