Section Three
COMPONENT ACCESS
COMPONENT LOCATION
Fig. 1
RECIRCULATION
PRESSURE DOME
DIVERTER
VALVE
OUT-OF-BALANCE
SWITCH
INLET
VALVES
OUTLET
VALVES
WATER LEVEL
TRANSDUCER
ELECTRONIC
CONTROL BOARD
RECIRCULATION
PRESSURE
SWITCH
