DIVERTER VALVE
Fig. 17
NOTE: The Diverter Valve is equipped with a plastic protective cover. If the diverter
valve is serviced or replaced the protective cover MUST be reinstalled.
FROM PUMP
RECIRCULATION
PRESSURE DOME
RECIRCULATION
PRESSURE
SWITCH
RECIRCULATION
SPRAY
TUB INLET
RECIRCULATION
HOSE
