4-15
6. To remove the direct spark ignition
control:
a) Disconnect plugs J1 through J8.
b) Remove the mounting screw.
c) Slide the board up and remove it from
the top corner bracket slots.
Slot J1
ScrewJ5 - J8
J2 - J4
Direct Spark Ignition Control
Slot
