4-26
11. Remove the indicated 5 screws from the
left or right side panel you wish to remove
(the left panel is shown below).
12. Pull the back of the side panel out from the
range approximately 45˚.
13. Push forward to unhook the three front
tabs from the chassis slots, and remove
the side panel.
Pull
Back Of
Panel
Out
45˚
Unhook
3 Front Tabs
From Slots
Side Panel Screws
(1 of 5)
