COMPONENT ACCESS
4-4
n
Multi-Door Freestanding Refrigerator
Machine Compartment Components (Continued)
5. Pull the inverter far enough away from the compressor to
disconnect the green chassis ground wire and the compressor
terminal block.
6. Access the compressor terminal block as shown in below
gure to make resistance checks. The compressor is part of
the sealed system.
A
A. Compressor terminal
To Next Page
