COMPONENT ACCESS
4-12
n
Multi-Door Freestanding Refrigerator
Accessing Refrigerator Compartment Components (Continued)
17. Pull forward the center divider and li out.
18. To remove the rails on the divider, remove the two screws
holding the divider.
NOTE: When removing rails on either sides of divider there is
a screw that goes into the rail on other side to help hold it.
Remove this screw also.
19. Remove rear support by sliding the rail to the le and pulling
the right side out and forward.
20. Remove side rail assemblies on both sides by liing up and
pulling forward.
A
A. Center Divider
To Next Page
