COMPONENT ACCESS
4-14
n
Multi-Door Freestanding Refrigerator
Accessing Refrigerator Compartment Components (Continued)
6. Remove tape to access deli air damper.
7. Disconnect wire harness.
8. Separate the fan motor from the housing. There are four
rubber isolators that secure the motor to the housing.
Remove the fan motor.
9. Grasp the top and boom of the thermistor housing and
depress while you pull out on the housing. The evaporator
thermistor is part of the RC wiring harness.
To Next Page
