Quick GuideEN
KEYLOCK - A long press (for 3 seconds) of MULTIZONE button, will
activate the KEYLOCK function. To deactivate the KEYLOCK, long press again.
DELAY -The start of the program may be delayed for a period of time
between 0:30 and 24 hours
The DELAY function cannot be set once a wash cycle has been started.
POWER CLEAN - Thanks to the additional power jets this option provides
a more intensive and powerful wash in the lower rack, in the specic area.
This option is recommended for washing pots and casseroles.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be o.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
MULTIZONE - If there are not many dishes to be washed, a half loading
may be used in order to save water, electricity and detergent. By default the
appliance washes dishes in all racks.
Please scan the QR code on your product in order to have more detailed information.
More information in the Daily Reference Guide on the website.
CLEANING AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
The lower spray arm may
be removed by pulling it
upwards.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code indicated on the energy label. The label also includes the model identi-
er that can be used to consult the https://eprel.ec.europa.eu database portal.
IEC 436
:
LOADING THE RACKS
CAPACITY: 14 standard place-settings
Xerox Fabriano
NaturalDry it is a convection drying system which automatically opens
the door during/after the drying phase to ensure exceptional drying per-
formance every day. The door opens at a temperature that is safe to your
kitchen furniture.
UPPER RACK
(loading example for the
upper rack)
Load delicate and light
dishes: glasses, cups, sa-
ucers, low salad bowls.
LOWER RACK
(loading example for the lower rack)
For pots, lids, plates, salad bowls, cutlery etc.
Large plates and lids should ideally be pla-
ced at the sides to avoid interferences with
the spray arm.
The lower rack has tip-up supports which
can be used in a vertical position when ar-
ranging plates or in a horizontal position
(lower) to load pans and salad bowls easily
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
CUTLERY BASKET
It is tted with top grids for improved
cutlery arrangement. It must only be
positioned at the front of the lower
rack.
Knives and other utensils with
sharp edges must be placed in the
cutlery basket with the points fa-
cing downwards or they must be
positioned horizontally in the tip-
-up compartments on the upper rack.
POWER CLEAN®
Power Clean® uses the special water jets in the rear of cavity to
wash more intensively the high dirty items. The lower rack has
a Space Zone, a special pull-out support in the rear of the rack
that can be used to support frying pans or baking pans in upri-
ght position, thus taking up less space.
Placing the pots/casseroles faced to the
Power Clean® component please activate
the POWER CLEAN® on the panel.
TROUBLESHOOTING
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher does not
ll the water. Display shows:
and F6, both On/O
and START/Pause LEDs are
blinking rapidly.
No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.
The inlet hose is bent.
Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher
and reboot.
The sieve in the water inlet hose is clogged; it is
necessary to clean it.
After having carried out the verication and cleaning, turn o and turn on the
dishwasher and restart a new program.
Dishwasher nishes the cycle
prematurely.
Display shows: F15 and both
On/O and START/Pause
LEDs are blinking rapidly.
Drain hose positioned too low or siphoning into
home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).Check for
siphoning into home sewage system, install air admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
Please scan the QR code on your product in order to have more detailed information.
