Whirlpool WHAROS5 - Parts List

27
Parts List
Key
No.
Part No. Description
1 1128-02-04 Cabinet, Left
2 1128-02-03 Cabinet, Right
3 WHEERF
Pre & Post Filter Cartridge Ù
4 WHEERM
RO Membrane Cartridge Ù
5 1128-02-HB
Repl. Manifold Assembly
(includes Key Nos. 6-13)
– 7333179
Diaphragm Kit (includes
Key Nos. 7, 8 & 2 of Key No. 6)
6
á
Diaphragm (2 req.)
7
á
Spacer Ring
8
á
Plunger
– 7333137
Check Valve Kit (includes
Key No. 10 & 2 of Key No. 9)
9
á
O-ring, Auto. Shutoff Cover (2 req.)
10
á
Check Assembly
– 7333145
Automatic Shutoff Kit (includes
Key No. 11, 4 of Key No. 12 &
6 of Key No. 13)
11
á
Automatic Shut-off Cover Assembly
12
á
Washer (4 req.)
13
á
Screw (6 req.)
Key
No.
Part No. Description
– 7333153
Flow Control Kit
(includes Key Nos. 14 & 15)
14
á
Elbow, Plug-in, 1/4 Stem x 1/4 Tube
15
á
Flow Control Insert
16 7205326 Storage Tank
– 7333161
Tank Connector Kit
(includes Key No. 17-19)
17
á
Connector, 1/4 NPT x 3/8 Jaco
18
á
Insert, 3/8” Tubing
19
á
Nut, 3/8” Tubing
20 7292682 Faucet, with base and electronics
21 7208489 Drain Adaptor
22 119-8600084 Water Supply Fitting, 1/4” Q.C.
¢
7301203
Sanitization Kit =
¢
7315189
Auxiliary Storage Tank =
¢
7161823
Tubing, 1/4” x 20’ - white p =
¢
7157280
Tubing, 3/8” x 20’ - white p =
¢
7314183 Coin Battery
¢
7279749 Dropper
Ù Please purchase replacement cartridges from the retailer where you bought your reverse osmosis system.
¢ Not illustrated.
= Not included.
p Tubing lengths for remote installations, direct replacement for colored lengths of tubing.
