3
Tools and Parts
Gather the required tools and parts before starting installation.
The parts supplied are in the washer basket.
Portable Installation
Parts supplied:
Flat washers for faucet
adapter and ll hoses
Silver, double-wire hose
clamp (for bottom of drain
hose)
Faucet adapter Fill-and-drain hose
Hose bracket
Tools needed for installation:
Pliers that open to
1
9
/
16
" (3.95 cm)
Utility knife
Flashlight (optional)
INSTALLATION REQUIREMENTS
Permanent Installation
Parts needed (not provided with washer):
NOTE: Replace inlet hoses
after 5 years of use to reduce
the risk of hose failure.
Record hose installation or
replacement dates for future
reference.
Inlet hoses with at washers
Parts supplied:
Drain hose with clamp
Cable tie
Leveling feet
Tools needed for installation
Pliers that open to
1
9
/
16
" (3.95 cm)
Utility knife
Flashlight (optional) Adjustable or open-end
wrench
9
/
16
" (14 mm)
Measuring tape Phillips screwdriver
Level
