4.2 Connect wires to corresponding terminal blocks
Matcheachlabeledwiretoit’scorrespondingterminalonthemountedthermostatbase.Inserteachlabeledwireinto
theholeofit’smatchingterminal,andusingthescrewdriver,tightenthescrewontheterminalblocksecurely.
RC
RH
O/B
RH
Takecarewhensecuringandroutingwiressotheydonotshorttoadjacentterminalsorrearofthermostat.Personalinjuryand/orpropertydamage
may occur.
