22
05 HMI BAR MOUNT
5.3 Data Clearance & Assist Modes
Data clearance
You can clear and reset the subtotal mileage (TRIP), average speed (AVG),
and maximum speed (MAX). After the HMI controller has been powered for 10
seconds, navigate to Function 1 screen, press and hold the Mode button (2)
until the CLEAR DATA window appears. Press the Up & Down button (4 & 5) to
select accordingly, then click and hold Mode button (2) to conrm selection.
To close the pop-up CLEAR DATA window, press Mode button (2) or leave the
HMI controls for 30 seconds.
Walk Assist
When bike is stationary, press and hold the down button (5) to activate Walk
Assist mode. The display will show the Walk Assist icon (circled) and the real
time speed shown above the Walk Assist icon. To stay in walk mode the down
button (5) must be held down.
To exit Walk Assist mode release the down button (5). The motor will
disengage operation, and the HMI screen will return to the Home screen.
2
4
5
WARNING - Proper use of walk-assist mode is important to prevent
loss of control and injury.
• Only use when dismounted.
• Keep both hands on the grips and ngers on one or both brake
levers so the motor power can be stopped immediately if necessary.
• Keep clear of the pedals while walking the eBike.
WARNING - Make sure the eBike system is turned off so that the
walk-assist mode cannot be accidentally activated when:
• Pushing the eBike without the walk-assist mode turned on.
• Transporting the eBike (lifting onto a car, bike rack or a train).
• Carrying the eBike up and down stairs.
• Performing any maintenance or service (e.g., placing the chain on a
chainring) or other drivetrain parts, pedals or xing a at tyre.
