09 HUB MOTOR
9.1 Product Information
WARNING! When installing the rear wheel ensure the hub motor
power cable is facing towards the oor as pictured above. This will
ensure the cable can reconnect to the battery. Incorrect Installation
could cause the cables to interact with rotating components
resulting in an accident or damage to the product.
PLEASE NOTE: The rear disc brake must be
installed with specic M5x8-10mm TORX screws and
tightened to 4Nm.
INFO: When connecting the power cable pay attention to alignment
arrows as pictured above.
WARNING! When removing or installing the rear wheel
make sure the power cable has been disconnected
to avoid accidents. Keep the power cable away from
moisture and debris when carrying out maintenance.
