widos ESI 4000 - Page 36

Kunststoffschweißtechnik
Spare parts list Chapter 7
WIDOS ESI - 4000
Pos. Name Piece Order no.
1 Sealing cap 1 J0214
2 Supporting frame ESI Niro 1 410111
3 Accessory bag 1 TAHW2
4 SD drive W7D 1 EG0612
5 SD card 1 GB 1 EPR0610
6 Front insertion, splash-water proof 1 EST0602
7 Support plate for card reader CNC 3.0 1 105107
8 Cap for SD slot 1 105115
9 Heat sink ESI 4000 1 4101022
10 Tapped bushing M6 10 x 16 4 HGEW-M61
11 Pan head screw M 6x22 DIN 7984 4 7984F022
12 Tooth lock washer M 6 DIN 6797 4 6797F
13 Spax button-head screw d 3,5x15 2 SPR3.5x15
14 Lens-head screw M 4 x 10 DIN 84 8 7380D010
15 Lower housing element ESI 4000 1 4101211
16 Seal for housing ESI 4000 2,7m DHW10
17 LCD display 1 EG01143
18 Plastic film keyboard ESI 4000 1 EF0641
19 Housing cap ESI 4000 1 4101212
20 Ambient temperature sensor 1 EE04042
21 Accessory bag ambient temperature sensor 1 TAHW1
22 Silicone hose without inner fabric 10 x 0,7 1,5m EA09ISHW1
23 Cable screw connection, plastic M 25 x 1,5 1 EVS25G
24 Angle screw connection, plastic M 25 x 1,5 1 EVWK25G
25 Counter nut M 25 x 1,5 1 EV2225
26 Connecting cable with isolated plug 1 EK5230
27 Cable screw connection, plastic M 16 x 1,5 1 EVS16G
28 Angle screw connection, plastic M 16 x 1,5 1 EVWK16G
29 Counter nut M 16 x 1,5 1 EV2216
30 Welding cable ESI 4000 complete 1 EKHW05
31 On - Off switch 2-pole 1 ES1040
32 Barcode reading pen 1 EG0600
33 Circular plug 103 connector plug 1 ESTHWRS2
34 Circular plug 103 strain relief 1 ESTHWRE2
35 Set of contacts 4 mm 1 set HWAF003
36 Set of shrink hoses blue yellow 1 set EA09SBG
37 Plastic sleeve with drill hole 5 mm 2 EHWKP
38 Retainer for wire spring bushing 4 mm 2 EHWKM
39 Card reader SD / MMC USB 2.0 1 EPR0611
40 Start code card 1 HWBA003
41 General card electro socket welding device 1 HWBA001
42 User card electro socket welding device 1 HWBA002
43 Electro socket round adaptor 1 HWAR001
44 Electro socket flat adaptor (optional) 1 HWAF001
45 Transportcase 1 TKESIA
46 Transport crate 1 TKESIH
18.07.2013 Working instruction WIDOS ESI 4000 Page 36 of 37
