Description of the product Chapter 1
10.12.2013 Working instructions WIDOS PSM 20 Page 7 of 31
1.4. Designation of the product
The product is designated by a type label.
It contains the type of the machine, the serial number and the year of construction.
1.4.1. Technical data
1.4.1.1. WIDOS PSM 20 General data
Welding pressure:
maximum 59 kN with 250 bar
Sheet size max.:
- length up to 2000 mm
- width up to 20 mm
Welding material: PE and PP
Fuse protection: 16 A
Dimensions (W x L x H):
appr. 950 x 2500 x 1200 mm
max. working pressure pneumatic; 6 bar
Emissions:
- By using the stated plastic materials during
operation within a temperature range of up to
260° C, no poisonous vapors are generated.
Ambient conditions
- Keep the workshop clean (no dust at the welding
area)
- If secured by an appropriate measurement that
allowed conditions for welding are indicated, it is
possible to work in any outside temperature
condition as far as the welder is not constrained in
its manual skill
- Avoid humidity
- Avoid strong sunlight
- Avoid strong wind
1.4.1.2.
Heating element
Power: 3,6 kW
Current: 15,6 A (± 10 %)
Voltage: 230 V (± 10 %)
Frequency: 50 Hz
Surface: anti-stick coated
Included components: - electronic temperature adjustment
- control lamp
- connection cable with shock-proof plug
