Gas safety mounting (for versions with heating element)
Using the Gas Oven
S The symbols on the control panel indicate the position of the knob.
In the case of thermal element of upper
burners, safety mechanism is activated
and cuts the gas immediately against
shutdown due to liquid overflow.
Figure 8 Figure 9 Figure 10 Figure 11
Press the knob and turn counterclockwise to high heat and/or temperature position on the panel.1.
If, as shown in Figure 11, the oven plug controls the top heater burner, press the knob and turn clockwise to the
grill/flame sign.
2.
Light the lighter according to the version of your oven. 3.
Press the Gas button and turn counterclockwise to high heat position.1.
Ignite the lighter according to the version of your range.2.
After ignition, push and hold the button for 3-5 seconds to activate the safety mechanism.3.
If no ignition occurs after pressing and releasing the switch, repeat the same action by pressing and holding the
switch for 15 seconds.
4.
Set to desired flame position.5.
After cooking is complete, move the oven switch to the right to turn off the top tip of the burner. 6.
Manual ignition hole
Furnace injector and power table
