WiiM Amp - 3. Technical Specifications

WIIM AMP USER MANUAL VERSION 1.0 10/29/23
8 | P a g e
3. TECHNICAL SPECIFICATIONS
Feature
Description
Power Input
100-240V 50/60Hz AC Power
Audio Output Quality
SNR: 108 dB
THD+N: 0.002% (-92 dB)
Network
802.11 b/g/n/ac 2.4 GHz and 5 GHz dual
bands Wi-Fi
10/100M Ethernet
Bluetooth
Bluetooth 5.1, A2DP, AVRCP
Support SBC, AAC Codec
Audio Input
HDMI ARC, Optical, RCA
Audio Output
Passive Speaker Terminal
Subwoofer Output
Audio Codec
MP3, AAC, ALAC, APE, FLAC, WAV, WMA,
OGG, AIFF
Streaming Protocol
AirPlay 2, Chromecast Audio, DLNA, Spotify
Connect, TIDAL Connect, Alexa Cast, DLNA,
Qplay 2.0, Squeezelite
Streaming Services in App
Spotify, Amazon Music, Deezer, TuneIn,
Tidal, Qobuz, SoundCloud, Pandora,
iHeartRadio, vTuner, Napster, Sound
machine, etc.
LED
Three-color status LED - Red, Green, and
White
6 Volume LED
Controls
Volume knob, play/pause, and more
Weight
1.84 kg (4.1 lbs)
Dimension
7.48” x 7.48“ x 2.48" (190 mm x 190mm x 63
