17WIKA operating instructions pressure transmitter, model IS-3
MM/YYYY country code based on 14095850.02 12/2014 EN/CN
EN
3.6 Time response
Settling time ≤ 2 ms (≤ 10 ms, for medium temperatures below -30 °C)
3.7 Accuracy data
Accuracy at reference conditions 0.50 % of span
Optional: 0.25 % (only for measuring ranges ≥ 0.25 bar and ≤ 1,000 bar)
Including non-linearity, hysteresis, zero oset and end value deviation
(corresponds to measured error per IEC 61298-2).
Non-linearity (IEC 61298-2) ≤ 0.2 % of span BFSL
Non-repeatability ≤ 0.1 % of span
Mean temperature coecient of zero
point (0 ... 80 °C)
Measuring range ≤ 0.25 bar: ≤ 0.4 % of span/10 K
Measuring range > 0.25 bar: ≤ 0.2 % of span/10 K
Mean temperature coecient of span
(0 ... 80 °C)
≤ 0.2 % of span/10 K
Long-term stability at reference
conditions
≤ ±0.2 % of span/year
Adjustability of zero point and span Adjustment is made using potentiometers inside the instrument.
Zero point and span: ±5 %
3.8 Operating conditions
Ignition protection types
(see product label)
■
II 1G Ex ia IIA T4/T5/T6 Ga
■
II 1G Ex ia IIC T4/T5/T6 Ga
■
II 1/2G Ex ia IIC T4/T5/T6 Ga/Gb
■
II 3G Ex ic IIC T4/T5/T6 Gc X
■
II 3G Ex nA IIC T4/T5/T6 Gc X
■
II 3D Ex tc IIIC T90 °C Dc X
■
II 1D Ex ia IIIC T135 °C Da
■
II 1/2D Ex ia IIIC T135 °C Da/Db
■
I M1 Ex ia I Ma
3.Specications

WIKA IS-3 Specifications

General

Output Signal	4 ... 20 mA, 2-wire
Power Supply	10 ... 30 VDC
Material	Stainless steel
Accuracy	≤ ±0.5 % of span
Temperature Range	-20 ... +85 °C
Ingress Protection	IP65
Long-term stability	±0.2 % FS per year
Process Connection	G 1/4, G 1/2, 1/4" NPT, 1/2" NPT
Electrical Connection	M12 x 1
