Ingress protection (per
IEC 60529)
The ingress protection depends on the respective electrical connection.
The stated ingress protection only applies when plugged in using mating connectors that
have the appropriate ingress protection.
■
Angular connector acc. to DIN EN 175301-803 A: IP 65
■
Circular connector M12 x 1 acc. to IEC 61076-2-101 A-COD: IP 67
■
Circular connector M16 x 0.75 acc. to IEC 61076-2-106: IP 67
■
Cable outlet IP 67: IP 67
■
Cable outlet IP 68 cable gland: IP 68
1)
■
Cable outlet IP 68 (continuous use in the medium): IP 68
2)
■
Cable outlet IP67 with protection cap: IP 67
3)
■
Bayonet connector acc. to MIL-DTL-26482: IP 67
■
Field case: IP 69K
1) 72 h / 300 mbar
2) Maximum pressure of the surrounding medium: 2 bar
3) Requirement: Avoidance of water collection in protection cap
Vibration resistance
(per IEC 60068-2-6, vibra-
tion under resonance)
■
Model IS-3: 20 g
■
Model IS-3 with eld case and cable outlet IP 67 with protection cap: 10 g
■
Measuring range > 1,000 bar and optional medium temperature ranges: 5 g
■
Field case combined with optional medium temperature ranges: 2 g
Shock resistance
(per IEC 60068-2-27,
mechanical shock)
■
Model IS-3: 1,000 g
■
Model IS-3 with eld case: 600 g
■
Measuring range > 1,000 bar, optional medium temperature ranges and cable outlet
IP 67 with protection cap: 100 g
■
Field case combined with optional medium temperature ranges: 50 g
3.Specications

WIKA IS-3 Specifications

General

Output Signal	4 ... 20 mA, 2-wire
Power Supply	10 ... 30 VDC
Material	Stainless steel
Accuracy	≤ ±0.5 % of span
Temperature Range	-20 ... +85 °C
Ingress Protection	IP65
Long-term stability	±0.2 % FS per year
Process Connection	G 1/4, G 1/2, 1/4" NPT, 1/2" NPT
Electrical Connection	M12 x 1
