WIKA S-10 User Manual

EN
21WIKA operating instructions pressure transmitter, model S-10
1604457.16 09/2017 EN/DE/FR/ES
Specications
Temperature error at 0 ... 80 °C Mean temperature coecient of zero point Measuring ranges ≤ 0.25 bar:
≤ 0.4 % of span/10 K
Measuring ranges > 0.25 bar
≤ 0.2 % of span/10 K
Mean temperature coecient of span: ≤ 0.2 % of span/10 K
Long-term stability at reference
conditions
≤ ±0.2 % of span/year
Reference conditions
Ambient temperature 15 ... 25 °C
Atmospheric pressure 860 ... 1,060 mbar
Humidity 45 ... 75 % r. h.
Power supply DC 24 V
Mounting position Calibrated in vertical mounting position with process connection facing downwards.
Time response
Settling time ≤ 1 ms
≤ 2 ms for output signal DC 0.5…4.5 V ratiometric and measuring ranges < 400 mbar, 10 psi
10.Specications

WIKA S-10 Specifications

General

Brand	WIKA
Model	S-10
Category	Transmitter
Language	English
