EN
23WIKA operating instructions pressure transmitter, model S-10
1604457.16 09/2017 EN/DE/FR/ES
Specications
Electrical connection
Short-circuit resistance S+ vs. U-
Reverse polarity protection U
+
vs. U-
Insulation voltage DC 500 V
Materials
Wetted parts Stainless steel
Non-wetted parts Case Stainless steel
Internal pressure transmission medium Synthetic oil
Instruments with a measuring range of >
25 bar relative do not contain any pressure
transmission medium (dry measuring cell).
Clamping nut PA
Angular connector PA
O-rings at the clamping nut NBR
Flat gasket VMQ
CE conformity
Pressure equipment directive
RoHS directive
EMC directive, EN 61326 emission (group 1, class B) and interference immunity (industrial application)
The existence of strong electromagnetic elds in a frequency range of < 2.7 GHz can result in increased measuring errors up to 1 %. Do
not install the instruments in the vicinity of strong electromagnetic sources of interference (e.g. transmitting devices, radio equipment),
or use sheath current lters where applicable.
For further specications see WIKA data sheet PE 81.01 and the order documentation.
10.Specications
