9. Electrical connections
WARNING!
Observethesafety-technicalmaximumvaluesforthe
connectionofthepowersupplyandthesensors,see
chapter10.3"Safety-technicalmaximumvalues".
Whenworkingonthetransmitters(e.g.installation/removal,
maintenancework)takemeasurestopreventelectrostaticdischarge
fromtheterminals.
WARNING!
Onlycarryoutinstallationinade-energisedstate!
Theconnectedwiresmustbecheckedtoensurethey
areconnectedproperly.Onlywell-securedwirescan
guaranteeafault-freeoperation.
Input
Sensor
Output
4...20mAloop
Forheadmountingandrailmountingcase,connectionclampsfortheHART
®
modemare
available.
