WIKA T32.1S User Manual

GB
11258421.0901/2012GB/D
WIKAoperatinginstructionstemperaturetransmitterT32.xS 17
6. Commissioning, operation
6. Commissioning, operation
Inhazardousareas,onlyusetemperaturetransmitters
thatareapprovedforthosehazardousareas.The
approvalismarkedontheproductlabel.
6.1 Grounding
Connection head BSS
grounded
Loopcircuit
Connection head BSS
grounded
groundedshield
Thermowell
withsensor
grounded
sensorwire
equipotentialbonding
T32.xS
Field housing/
switch cabinet
Forthermocouples,additionallygroundhere!
ThemodelT32.1Stemperature
transmittershouldonlybeused
withgroundedthermometers!
ForgroundingofthemodelT32.xS
temperaturetransmitterseesafety
instructionspage9f.
