WIKAoperatinginstructionstemperaturetransmitterT32.xS 19
Mounting on the measuring insert
Mountthetransmitteronthecircularplateofthemeasuringinsert
usingtwocountersunkM3screwsperENISO2009.Appropriate
threadedinsertshavebeenpress-ttedintheundersideofthecase.
Assumingthecountersinkingiscarriedoutcorrectly,thepermissible
screwlengthcanbecalculatedasfollows:
Checkthescrewlengthbeforexingthetransmittertothemeasuring
insert:insertthescrewintothecircularplateandverifylengthof4mm!
CAUTION!
Donotexceedthemaximumpermissiblescrewlength!
Thetransmitterwillbedamagedifthescrewsarescrewed
furtherthan4mmintothebottomofthetransmitter.
Mounting in connection head
Insertthemeasuringinsertwiththemountedtransmitterintothe
protectivesheathandsecureintotheconnectingheadusingscrews
inpressuresprings.
3173801.C
l
max.
=s+4mm
with
l
max.
Lengthofscrewinmm
s Thicknessofcircular
plateinmm
3173801.B
max.4
Circularplate
l
s
6. Commissioning, operation
Installation by means of DIN rail adapter
Ifthemechanicaladapter,availableasanaccessory,isusedthe
T32.1SheadtransmitterscanalsobexedonaDINrail.
