WIKA T32. S Series User Manual

GB
11258421.0901/2012GB/D
20 WIKAoperatinginstructionstemperaturetransmitterT32.xS
6.3 Conguration
Thefollowingparameterscanallbecongured:sensormodel,sensor
connection,usermeasuringrange,outputlimit,alarmindication,
terminalvoltagemonitoring,sensorbreakmonitoring,measuring
rangemonitoring,measuringrate,damping,writeprotection,oset
values(1-pointcorrection),TagNo.anduserlinearisation(custom
chararcteristiccurve).Furthermore,alineartransformationofthe
processvalueispossibleusinga2-pointcorrection.
Userlinearisation:
Viasoftware,customer-specicsensorcharacteristicscanbestored
inthetransmitterinordertodeneothersensortypes.Numberof
auxiliarypoints:min.2;max.30.Ifmorethan2sensorsareconnected
(dualsensorfunction)furthercongurationscanbecarriedout.With
thedualsensorfunction,twoidenticalsensors(resistancesensoror
thermocouple)withthesamemeasuringrangeareconnectedand
thenprocessedtogether.
Thetransmittersaredeliveredwithabasicconguration(seedata
sheetTE32.04)orconguredaccordingtocustomerspecications.
Ifthecongurationischangedafterwards,themodicationsmustbe
notedonthelabelusingawater-resistantfelt-tippen.
Asimulationoftheinputvalueisnotrequiredtocongure
theT32.
Asensorsimulationisonlyrequiredforthefunctionaltest.
6. Commissioning, operation
6.2.2 Transmitter in rail mounting version (model T32.3S)
Fastentherailmountingcase(modelT32.3S)ontoa35mmtop-hat
rail(EN60175)bysimplylockingitintoplacewithouttheneedforany
tools.
Disassemblyisachievedbyunlockingthelockingelement.
