23WIKA operating instructions, models TRxx and TCxx
14150915.08 04/2024 EN/DE/FR/ES
Increasing the distance of the connection components to hot surfaces
The length X is defined as the distance between the transition point from the cable to
the heat-emitting surface. The expected temperature at the transition point should be a
maximum of 120 °C [248 °F].
▶
If necessary, the X length should be increased.
11355647.01
Thread
Thread
(NPT)
5. Commissioning and operation
