Hydraulic Fluid
You will need 2.6 gallons of AW-32 or ISO-32 hydraulic fluid. DO NOT USE
DEXRON® IN THIS LIFT! This tank will hold approximately 10.5 quarts (2.6
gallons).
Items included in your package (Parts List)
✓ Runways-Left and Right, fastened to end brackets, runway one containing ram
and cables on top and runway two is fastened to the bottom of the end bracket,
flipped upside down.
✓ Steel Approach Ramps-2
✓ Approach Ramp Mounting Brackets-4
✓ Hydraulic Power Unit- Packaged in its own box marked Power Unit
✓ Upright columns- 4, 2 left, 2 right with top caps inserted on top of each post
✓ Crossbeams-2
✓ Parts Box- Labels with list of small parts contained in the box (listed on page 8)
✓ Safety Linkage Rods-2, one containing a release handle
✓ Rolling Jack Tray
✓ Wheel Safety Stops-4
✓ Hydraulic Hose
✓ Casters-Set of 4, 2 left and 2 right
✓ Power Unit Mounting Bracket
✓ Pulley Covers-4
