Will Burt Night Scan Chief - Figure 1-2 Mast Loads

Night Scan Chief
Mast Loads
It is important that the mast be securely mounted to a sturdy platform, which will not overturn during
operational loading of the mast. Figure 1-2 provides loading information for the mast, which can be
expected during operation. All values given are in lbs.
35# 200# 200#575# 575#
Figure 1-2 Mast Loads
