Table 5-2. Remote Control Positioner Assembly Parts List
Mark No. Description Part Number
1 Remote Control Positioner Frame 4124102
2 Circuit Board, RCP 4118401
3 Pan Bearing Housing 4124302
4 Tilt Coupling 4124801
5 Horizontal Bearing 913435
6 Bearing Retainer 4124202
7 Pan Bearing Spacer 4124401
8 Pan Gear 4124901
9 Pan Flag 4125201
10 Card Guide 913881
11 Terminal Bracket 4125401
12 Shim Washer 4203701
13 Key 4120802
14 Terminal Block 215001
15 Snap Ring 3401
16 Motor Assembly 4205001
17 Pan Bearing 3868
18 Flat Washer 3872
19 Snap Ring 4208001
20 O-Ring, PTFE 3398
21 Tilt Flag 4125101
22 Flag Mounting Ring 4125301
Revision 1 5-4
