27
DRAWING
REF NO.
PART NUMBER DISCRIPTION
1 P323834 VENT LIMIT SWITCH
2 M116840 CIRCULATION FAN ASSEMBLY
3 P323828 HIGH LIMIT SWITCH
4 M117504 COMBUSTION WELD ASSEMBLY
5 P323750 FLAME SENSOR
6 P323762 THERMOCOUPLE PROBE
7 P323742 HOT SURFACE IGNITER
8 M117255 SIGHT WINDOW
9 M117149 CONTROL BOARD
10 9C167 FRONT PANEL
11 M117435 VENT SAFETY SWITCH
12 M117283 HEADER ASSEMBLY
13 M117345 DRAFT HOOD ASSEMBLY
14 M117285 HEAT EXCHANGER TUBE ASSEMBLY
15 M116865 SHIELD ASSEMBLY
16 M117148 IGNITION MODULE
17 P323777 ORIFICE
18 323732 COMBUSTION FAN
19 323806 PRESSURE SENSOR
20 P323790 MANIFOLD ASSEMBLY
21 P323822 STEPPER GAS VALVE
22 M117162 ELECTRONIC HEAT SHIELD
23
M117501
M117502
M117503
P323068
P323740
P323783
P323784
LABEL PLATES
24 P323744 THERMOSTAT
