3
APPLICATION OF THE PUMP
SPECIFICATIONS OF THE PUMP
▶
The pump is suitable for boosting low water pressure in apartment houses, apartments, weekend
cottages, inns, houses, small sprinklers, school buildings, dormitories, and other buildings,
providingconstant water pressure.
※ Water flow rate, water pressure(head), voltage, motor output are referred to on the nameplate.
Basic conditions are:
▶
The embedded converter for constant pressure enables control of the operating pressure depending
on the height of a building.
▶
Pressure gauge is engaged to show pump pressure.
▶
Pressure tank is attached to prevent rapid change of pressure in piping.
▶
The stainless steel pump and brass piping will remain free of rust stains.
FEATURES
▶ Adjusting pressure setting
▶ Overpressure protection
▶ Auto restart after electricity failure
▶ Auto restart after correcting errors
▶ Dry running protection and zero flow detection
▶ Optional operating modes: Pressure regulation mode, Constant speed mode, External signal control
▶ Information and alarm signs are indicated on the display, helping easy search
STAINLESS HORIZONTAL MULTI-STAGE PUMP
▶ The pump forms block-typed structure and every pump parts in contact with water is corrosion
resistant. (Approved by KTW and WRC)
▶ The pump is equipped with Mono-Shaft, general-purpose mechanical seal, and plugs for suction and
discharge.
Ambient temperature
Ambient humidity
Power consumption
0~40°C (32~104°F) Location Indoors
Pressurized condition
VVVF
Up to 80°C
centrifugal pump (horizontal
multi-stage stainless steel pump)
Suction condition
Inverter control
Liquid Temperature
Pump
A relative humidity under
90% (no condensation)
Single phase
220V 60Hz
