English
74 WILO SE 10/2013
Menu item appears only if an IF Module
Stratos was plugged into the 0-10 V input
The "10V" symbol appears in the display
Switching 0-10V input on / off
Activating the 0-10V input:
The display indicates "ON" and the "module motor
symbol".
The setpoint cannot be selected manually using the
control button. "10V" is indicated in the basic set-
ting .
The setting can be changed by turning
the control button.
Deactivating the 0-10V input:
The display indicates “OFF”.
The setting is applied.
If the input was activated, the menu navigation
jumps to menu item .
If no input voltage is applied at the 0-10 V contact,
"Off" appears on the display and the "motor sym-
bol" is not displayed.
LC display Setting
