Drinking water circulation
systems with resistance in
the generator circuit  50%
of the resistance in the
ascending section
5. Drinking water circulation systems
with thermostatically controlled line
shut-off valves
p-c
Heating systems 1. Two-pipe systems
• Pump is installed in the feed pipe.
• The feed temperature is controlled
by atmospheric conditions.
An increasing feed temperature
increases the flow rate.
2. One-pipe systems
• Pump is installed in the return pipe.
• The feed temperature is constant.
A falling feed temperature reduces
the flow rate.
3. Primary circuits with condensing
boiler
• Pump is installed in the return pipe.
A falling feed temperature reduces
the flow rate.
p-T
Drinking water circulation
systems
4. Drinking water circulation systems
with thermostatically controlled line
shut-off valves or constant flow rate.
If the temperature is increased in the
circulation pipe, the flow rate is
reduced.
Heating-ventilation/air-
conditioning systems
Drinking water circulation
systems
1. Constant flow rate Manual
control mode
Heating systems 1. All systems
• Pump is installed in the feed pipe.
• The feed temperature falls during
low load periods (e.g. at night).
• The pump runs 24 hours without
external control at the mains.
Setback
operation
System type System conditions Recommended
control mode

Wilo Stratos-D Series Specifications

General

Application	Heating
Connection Type	Flange connection
Fluid Temperature Range	-10 °C to +120 °C
EEI	≤ 0.20
Display	LCD
Power Consumption	Varies depending on model
Housing Material	Cast iron
Motor Type	EC motor
Energy Efficiency Class	A
