Woofer Damping Resistor
There is a 18.6 ohm barrel resistor for woofer level. The 3.56 ohm Q resistor af-
fects Woofer Damping, which in turn affects the way the Alexia’s woofers couple to the
amplifier. Both of these resistors are pre-installed in the base of the Bass Module and
should not be changed by the end user.
A l e x i A O w n e r ’ s M A n u A l
48
Wilson Audio Specialties
figure 16—Mid & tweeter resistOr Are AttAched tO heAtsinks with Allen hArdwAre�
