Wilson Audio Specialties
s e C T i O n 6 . 1 – T r O u b l e s h O O T i n g
Enclosure Type Tweeter Module:
Enclosure Type Midrange Module:
Enclosure Type Woofer Module:
Woofers:
Midrange:
Tweeter:
Sensitivity:
Nominal Impedance:
Minimum Amplifier Power:
Frequency Response:
Overall Dimensions:
Alexia Weight Per Channel:
Sealed, X-Material
Rear Vented, X- & S-Material
Rear Ported, X-Material
One—8 inch (20.32 cm) Paper Pulp
One—10 inches (25.4 cm) Paper Pulp
7 inch (17.78 cm) Paper Pulp Composite
1 inch (2.54 cm) Doped Silk Fabric
90 dB (one watt at one meter at 1Khz)
4 ohms/minimum 2 ohms @ 80 Hz
20 watts per channel
20 Hz—32 kHz +/- 3 dB
(with port contribution)
Height—53 1/4 inches (135.29 cm)
Width—15 1/4 inches (38.74 cm)
Depth—21 1/8 inches, (53.7 cm)
256 lbs (116.12 kg)
