Wilson
®
Electronics, Inc.
Phone:8662941660 www.wilsonelectronics.com Fax:4356562432
Part#110435AIGMW043/12.28.07
AmplifierSpecifications
DualBand
800/1900MHzSpecifi cations
ModelNumber/PartNumber 271245/801201
Connectors FMEMale
Impedance(input/output) 50ohms
Dimensions 5.6x3.6x1.7inchor14.2x9.1x4.4cm
Weight 1.44lbsor0.65kg
Frequency 824894MHz/18501990MHz
1
PassbandGain(nominal)
800MHz 50dB
1900MHz 60dB
2
20dBBandwidth(nominal)
800MHz(uplink/downlink) 53.5MHz/47.7MHz
1900MHz(uplink/downlink) 86MHz/83MHz
Poweroutputforsinglecellphone(uplink) 800MHz 1900MHz
CDMA +30.9dBm +30.5dBm
GSM +30.0dBm +29.7dBm
EDGE +30.4dBm +30.3dBm
AMPS +30.2dBm
3
Poweroutput(uplink)formultiple
cellphones:
Numberof
cellphones
MaximumPower
800MHz 1900MHz
2 +25.0dBm +24.7dBm
3 +21.5dBm +21.2dBm
4 +19.0dBm +18.7dBm
5 +17.0dBm +16.7dBm
6 +15.5dBm +15.2dBm
Poweroutputforsinglereceivedchannel
(downlink)
800MHz 1900MHz
CDMA +10.0dBm +9.9dBm
GSM +11.0dBm +9.9dBm
EDGE +10.9dBm +9.6dBm
AMPS +10.3dBm
4
Poweroutputformultiplereceived
channels(downlink). Themaximum
powerisreducedbythenumberof
channels:
Numberof
channels
MaximumPower
800MHz 1900MHz
2 11.6dBm 3.1dBm
3 15.1dBm 6.6dBm
4 17.6dBm 9.1dBm
5 19.6dBm 11.1dBm
6 21.1dBm 12.6dBm
NoiseFigure(typical) 3dBnominal
Isolation >90dB
PowerRequirements
AmplifierUsage 6V,.5A1.5A(subjecttouplinkpower)
Notes:
1.Nominalgainisthemaximumgainatanyfrequencyinthepassband.
Averagegainsare:37dB(800MHzuplink&downlink)45dB(1900 MHzuplink&downlink)
2.Nominalbandwidthisthedifferencebetweentwofrequenciesthatareadjacenttothepassbandwheretheamplifica tionis20dB
lowerthanthepassbandamplification.Oneofthefrequenciesislowerthanthepassbandandtheotherishigher.
3.TheManufacturer’sratedoutputpowerofthis equipmentisforsinglecarrieroperation.Forsituationswhenmultiplecarrier
signalsarepresent,theratingw ouldh avetobereducedby3.5dB,especiallywheretheoutputsignalisreradiatedandcan
causeinterferencetoadjacentbandusers.Thispowerreductionis tobebymeansof inputpowerorgainreductionandnotby
anattenuatorattheoutputofthedevice.
4.Themaximumpowerfor2ormoresimultaneoussignalswillbereducedby6dBeverytimethenumberofsignalsisdoubled.
