BeforeGettingStarted
ThisguidewillhelpyouproperlyinstallWilson’sdualband,mobilewirelessamplifier.Itis
importanttoreadthroughalloftheinstallationstepsforyourparticularapplication
priortoinstallinganyequipment.Readthroughtheinstructions,visualizewhereallthe
equipmentwillneedtobeinstalledanddoasoftinstallationbeforemountinganyequipment.
Ifyoudonotunderstandtheinstructionsinfull,seekprofessionalhelp,orcontactWilson
TechnicalSupportat8662941660.
Warning:Inawirelessinstallation,
donotplugtheamplifierdirectlyintothe
cellphoneordatacardusinganantenna
adapter.Itwilldamagetheamplifier.
!
Out side
Antenna
Insid e
Antenna
Amplifier
DCPower
Supply
CellPhone
PDA
Note book
Out side
Antenna
Amplifier
DCPower
Supply
CellPhone,PDAor
Note book with
universalconnector
attached(seepg. 7)
InstallationDiagram
InsideAntenna
Warning:Inawirelessinstallation,
donotplugtheamplifierdirectlyintothe
cellphoneordatacardusinganantenna
adapter.Itwilldamagetheamplifier.
!
InstallationDiagram
UniversalConnector
