InstallationInstructionsfortheFollowingWilsonAmplifier:
MobileWirelessDualBandAmplifier
Model#271245,Part#801201
FCCID:PWO8012SM IC:4726A8012SM
Theterm“IC”beforetheradiocertificationnumberonlysignifiesthatIndustryCanada
technicalspecificationsweremet.
InsidethisPackage
HowitWorks
YournewWilsonamplifierhasbeencarefullyengineeredtosignificantlyimprovethe
performanceofyourcellphoneorcellulardatacardinmobileapplications.Togetherwith
anoutsideantenna(soldseparately),theamplifier’sstateofthearttechnologyisdesigned
toincreaseyoursignalupto10times,reducedisconnectsanddropouts,andincreasedata
communicationratesneededfor3Gtechnologies.
Theoutsideantennawillcollectthecelltowersignalandsenditthroughthecabletothe
amplifier.Thesignalisthenboostedandsentthroughtheinsideantennaortotheuniversal
connector,dependingonyourapplication.Yourcellphoneordatacardthencommunicates
withtheimprovedsignal.Whenthecellphoneordatacardtransmits,thesignalgoes
throughtheinsideantennaortheuniversalconnector,isboostedbytheamplifierand
broadcastbacktothecelltowerthroughtheoutsideantenna.
WilsonElectronicsmanufacturesawidevarietyofantennastohelpyoucustomizeyour
amplifierforyourspecificapplication.Severalareshownbelow.Seeyourdealerorvisit
www.wilsonelectronics.com.
Wir eless
amplifier
DCplugin
powersupply
Lowprofile
antenna
(OptionAseep.6)
Universal
Connector
(OptionBseep.7)
NMO
Mount
DualBandMagnet
Mount
DualBand
Trucker
Mount
DualBand
Mini
Magnet
DualBand Marine
Antenna
DualBand
NOTE: Useo fthisa mplifierwithan
antennagainhigherthan6.12dBiisin
violationofFCCregulationsforwhichthe
offenderisfullyliable.AllWilsonmobile
antennasare6.1 2dBior less.
