Typical Installation
Power
Supply
Signal
Booster
Lightning
Surge Protector
(Recommended)
Inside Panel
Antenna
Before Getting Started
This guide will help you properly install your Wilson Electronics
Signal Booster. It is important to read through all of the
installation steps for your particular application prior to
installing any equipment. Read through the instructions,
visualize where all the equipment will need to be installed and do
a soft installation before mounting any equipment. Contact
Wilson Electronics Technical Support Team with any questions
at: 866-294-1660.
2-way/3-way/
4-way splitter
(if using multiple
inside antennas)
(Optional third
antenna for
additional
coverage).
