Amplier Specications
Dual Band
900/1900 MHz Specications
Model Number
2B4310
Connectors FME-Male
Impedance (input/output)
50 Ohms
Dimensions 5 x 3.5 x 1.2 inch or 12.7 x 8.9 x 3 cm
Weight 1.03 lbs or 0.468 kg
Frequency 896-940 MHz / 1850-1990 MHz
1
Passband Gain (nominal)
25 dB typical, 30 dB maximum
2
20 dB Bandwidth (nominal)
900 MHz 8 MHz maximum
1900 MHz 74 MHz maximum
³Power output for single cell phone (uplink) 900 MHz 1900 MHz
CDMA
29.0 dBm
GSM
29.2 dBm
EDGE
29.0 dBm
iDEN
29.6 dBm
Power output for single received channel
(downlink)
900 MHz 1900 MHz
CDMA
8 dBm
GSM
8 dBm
EDGE
8 dBm
iDEN
-6.6 dBm
4
Power output for multiple
received channels (downlink).
The maximum power is reduced by
the number of channels:
Number of
channels
Maximum Power
900 MHz 1900 MHz
2 5.8 dBm 13.3 dBm
3 2.2 dBm 9.8 dBm
4 -0.3 dBm 7.3 dBm
5 -2.2 dBm 5.3 dBm
6 -3.8 dBm 3.8 dBm
Noise Figure (typical) 3.5 dB nominal
Isolation
uplink/downlink more than 50 dB
Power Requirements 12 V, 2 A (subject to uplink power)
Notes:
1. Nominal gain is the maximum gain at any frequency in the passband.
2. Nominal bandwidth is the difference between two frequencies that are adjacent to the passband where the amplication is 20 dB
lower than the passband amplication. One of the frequencies is lower than the passband and the other is higher.
3. The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier
signals are present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can
cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by
an attenuator at the output of the device.
4. The maximum power for 2 or more simultaneous signals will be reduced by 6 dB every time the number of signals is doubled.
3301 East Deseret Drive, St. George UT 84790
For additional Technical Support visit
www.wilsonelectronics.com
Phone: 866-294-1660 Fax: 435-656-2432
Part #110481 AIG SBi 007 / 02.11.08
