Installation Instructions for the Following Wilson Amplier:
SIGNALBOOST
™ 900/1900 MHz iDEN Amplier
Model #2B4310, Part #814310
FCC ID: PWO2B4310SM IC: 4726A-2B4310SM
Patent Pending
The term “IC” before the radio certication number only signies that
Industry Canada technical specications were met.
Inside this Package
How it Works
Your new Wilson SIGNALBOOST™ Amplier has been carefully engineered to signicantly
improve the performance of your cell phone or cellular data card. Together with an antenna,
the amplier’s state-of-the-art technology is designed to increase your signal up to 10-15
times, reduce disconnects and dropouts, and increase data communication rates needed
for 3G technologies. The universal connector works with all iDEN data cards.
The antenna will collect the cell tower signal and send it through the cable to the amplier.
The signal is then boosted and sent through the extension cable to either the universal
connector on your data card or the cradle antenna with your cell phone, which then
communicates with the improved signal. When the cell phone or data card transmits, the
signal goes through either the universal connector or the cradle antenna, is boosted by the
amplier and broadcast back to the cell tower through the antenna.
NOTE:
Use of this amplier with an antenna gain higher than 6.12 dBi on a vehicle or within
a building is in violation of FCC regulations. All Wilson mobile antennas have 6.12 dBi or
less gain. Use of this amplier with an outside xed building antenna gain exceeding 15 dBi
is in violation of FCC regulations. All Wilson Yagi antennas have gains of 15 dBi or less.
Use of antennas with higher than the above maximum allowable gains is in violation of FCC
regulations for which the offender is fully liable.
SIGNALBOOST
™
amplier
12 V DC power
supply (vehicle)
Universal
connector
VELCRO
®
Adhesive
Bracket
Adhesive/Screw
Swivel Bracket
Air-vent
Bracket
Cell Phone
Cradle Plus
