Windsor 10080480 User Manual

3386302100 CLIPPER DUO
Brush Deck
*SEE SERIAL NUMBER PAGE.
**CALL MANUFACTURER FOR SERIAL NUMBER
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86223780 8 SCR, M4X8, SET, ISO4029,CP,BLK
2 86224170 2 SHAFT, 6.2MM BRUSH DRIVE
3 86012800 2 SHAFT ASM, BRUSH END CAP
4 86012810 1 SHAFT, ASM, DRIVE 16"
5 86223520 3 RING, 28MM INT SNAP PHOSPHATE
6 86223310 1 PULLEY, 5MM HTD, 18T, 12.7 ID
7 86215250 1 BELT, 2S 5MM HTD, 15W, 128T
8 86224660 1 SPRING, TENSIONER
9 86173330 1 WASHER, M5 FLAT, ISO7093 SS
10 86014990 9 SCR, M5X20, SHCS ISO4762, SS
11 86215870 1 BRKT, TENSIONER ARM
12 86012780 2 PULLEY ASM, 5MM HTD 22T
13A 86216050 1 BRUSH, EXTRACTOR 16"
13B 86295520 1 BRUSH, EXTRACTOR 16" NATURAL
14 86223490 2 RING, 10MM EXT SNAP, DIN 471
15 86224130 1 SHAFT, TENSIONER
16 86343870 1 HOUSING ASM, BRUSH DRIVE **
17 86294070 1 PULLEY, 36T 5MM HTD
18 86012790 2 SHAFT ASM, BRUSH DRIVE
19 86172970 3 SCR, M5X12, PHLP FHMS, ISO7046, SS
20 86222870 1 PLATE, BRUSH DRIVE COVER
21 86217780 1 EXTRUSION, DUAL BRUSH 16"
22 86219390 1 HOUSING, BRUSH CLIP
23 86173350 4 WASHER, M5, FLAT, ISO7089,SS
24 86172980 2 SCR, KA50X10, PT OHS, WN14112, PLTD
25 86224630 2 SPRING, BRUSH CLIP
26 86277130 7 SCR, 5/16-18 X 1.00 CARRIAGE SS
27 86215230 1 BEARING, BRONZE FLANGED
28 86294060 1 PULLEY, 30T 5MM HTD
29 86350490 3 PLUG, HOLE, 5MM DIA X 12 MM L
